Electric Tractor Trucks
Dongfeng KL MAX platform electric prime movers — LvKong permanent-magnet motors, CATL LFP batteries and 4-speed AMT. Configurations from 4x2 port haulage at 42 t to 6x4 ultra-heavy 120 t mining tractors, with RHD and CCS2 Euro-spec versions.
4x2 Light-Duty Tractor — Port & City Logistics
Side-mounted battery lowers the centre of gravity; a compact 42 t prime mover that slips through port gates and urban corridors on a single charge.
TE46
KL MAX cab, 4x2, 42 t GCW. CATL 400 kWh, LvKong 315/510 kW motor, 4AMT. EBS+ESC, LDWS+FCWS, LED headlights and air-suspended cab. Ideal for port and urban logistics.
TE4Z
KL MAX cab, 4x2, 42 t GCW. CATL 400 kWh, LvKong 315/510 kW motor, 4AMT. CCS2 charging for European compliance. Same chassis and comfort as the TE46.
6x4 Heavy-Duty Tractor — Line Haul & Heavy Load
From 49 t highway combinations to 120 t mining road trains — one family of reinforced frames, high-torque e-motors and dual-gun 600 A fast charging.
TE8L / TE8K
Line-haul tractor, CATL 400/466/600 kWh, LvKong 315/510 kW, 4AMT. EBS+ESC, LDWS+FCWS. TE8L uses GB/T, TE8K switches to CCS2 for the European market.
TE9L / TE9B
TE9L strips weight for best-in-class efficiency at 49 t; TE9B adds payload headroom to 65 t. CATL 400/497/600 kWh, LvKong 350/520 kW, DF601S/DF162E axles, 600 A dual-gun charge.
TE8M
Heavy-haul tractor for coal and ore. Reinforced 300x90x8+6 frame, CATL 466/497/600 kWh, LvKong 400/550 kW, DF701S/DF485 axles. Built to earn on the hardest routes.
TE8P
Maximum pulling power. CATL 400/600 kWh, LvKong 400/550 kW, 9/13 parabolic suspension, DF300H rear axle and 12.00R20 tyres for extreme combination loads.
TE9Y / TEAY
Purpose-built RHD tractors for Nigeria, Kenya, South Africa, Australia and India. CATL 400–600 kWh with LvKong 400/550 kW; TEAY mirrors the reinforced TE8M chassis for RHD haulage.
TE Series in Pictures
Official Dongfeng brochure photography of the KL MAX electric tractor family — from 4x2 port movers to 120-tonne heavy haulers.
Built for Line Haul, Port and Mining Routes
Every TE tractor is validated over 12,500 km of reliability testing with 323 component tests — then tailored to your road, load and climate.
- 4x2 TE46 / TE4Z for port shuttling and urban distribution
- 6x4 TE8L / TE9L for 49 t international line haul
- TE8M / TE8P for coal, ore, steel and 80–120 t combinations
- TE9Y / TEAY right-hand drive for RHD markets
- Air-suspended cab, LDWS+FCWS and ECE R29-03 cab strength
Charge or Swap — Keep the Fleet Moving
Dual-gun fast charging up to 600 A cuts 20–80% SOC time to about 40 minutes; select battery-swap architectures enable continuous 24/7 duty.
- GB/T (China / Africa / Middle East) and CCS2 (Europe) interfaces
- CATL LFP chemistry: 8-year / 4,500-cycle warranty
- Energy recovery via EBS improves efficiency up to 20%
- HD battery thermal management for hot and cold climates
- 60–80% fuel-cost saving versus diesel per kilometre
Technical Specifications Summary
Full factory specification sheets are available on request — variants shown below are the standard export configurations.
| Model | Drive | Battery | Motor | GCW | Charging |
|---|---|---|---|---|---|
| TE46 | 4x2 | CATL 400 kWh | LvKong 315/510 kW | 42 t | GB/T dual 500 A |
| TE4Z | 4x2 | CATL 400 kWh | LvKong 315/510 kW | 42 t | CCS2 dual 500 A |
| TE8L | 6x4 | CATL 400/466/600 kWh | LvKong 315/510 kW | 49 t | GB/T |
| TE8K | 6x4 | CATL 466/600 kWh | LvKong 315/510 kW | 49 t | CCS2 |
| TE9L | 6x4 | CATL 400/497/600 kWh | LvKong 350/520 kW | 49 t | GB/T dual 600 A |
| TE9B | 6x4 | CATL 400/497/600 kWh | LvKong 350/520 kW | 65 t | GB/T dual 600 A |
| TE8M | 6x4 | CATL 466/497/600 kWh | LvKong 400/550 kW | 80 t | GB/T dual 600 A |
| TE8P | 6x4 | CATL 400/600 kWh | LvKong 400/550 kW | 120 t | GB/T dual 600 A |
| TE9Y | 6x4 RHD | CATL 600 kWh | LvKong 400/550 kW | — | GB/T |
| TEAY | 6x4 RHD | CATL 400 kWh | LvKong 400/550 kW | — | GB/T |
Explore Other Dongfeng EV Lines
Electric Dump
Construction and mining tippers from 31 to 80 t with reinforced frames and swap-battery options.
Electric Cargo
Box, flatbed and livestock trucks with up to 70 m³ bodies and 400 km of real-world range.
Electric Special
Sprinklers, sweepers, garbage trucks and concrete mixers for municipal and construction fleets.
Find the Right Electric Tractor
Tell us your gross combination weight, route profile and charging setup — we will recommend the right TE configuration and quote factory-direct within 24 hours.
